Torque Converters
Transend - Products List
Remanufactured, 10.75" Body Diameter, Milled Flats Hub Type, 4 Mounts, Pad Mount Type, 9.125" Bolt Circle, 1.335" Pilot Outside Diameter, 0.99" Pilot Length, No Ring Gear, 893AB Stamped Codes, 2000-2400 Stall, 22 Turbine Splines, Electronically Modulated Converter Clutch Grooved Clutch Friction Type, Lock-Up
42RLE, 42LE
Login for personalized shopping
All New Components Converter, Pilot Dia. 21MM, Hub Dia. 39.65MM, Body Dia. 267MM, 4 Studs, Replaces Both Solid and Hollow Type Pilots. OE Reference Number Interchange, CV6Z-7902-FRM, DG9Z-7902-H, EG9Z-7902-E, GN1Z-7902-A, 9L8Z-7902-ARM, 9L8Z-7902-H, 9L8Z-7902-L
6F35
Login for personalized shopping
Lock-Up, 2 Sided Friction, 13.425" Overall Diameter, 12.250" Bolt Pattern, 6 Holes Mount w/ 10mm x 1.5 Thread, 4 Flats w/ Groove Hub, 2.124" Pilot Diameter, 27 Spline, 1350 Stall Speed; 671AD, 671AE, 671AF, 671AG, 671AH, P52119671AG Stamped Codes
68RFE
Login for personalized shopping
Remanufactured, 12.75" Body Diameter, Milled Flats Hub Type, 4 Mounts, Stud Mount Type, 11.375" Bolt Circle, 1.375" Pilot Outside Diameter, No Ring Gear, A, AA, E, F, H, M, O, SS, U Stamped Codes, 2000 Stall, 31 Turbine Splines, Lock-Up
E4OD, 4R100
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Slotted Stepped Hub Type, 3 Mounts, Stepped Pads Mount Type, 11" Bolt Circle, 1.701" Pilot Outside Diameter, No Ring Gear, JMBX, 24236469, 24239789, 24245964, 24243221 Sticker Codes, Low Stall, 36 Turbine Splines, Lock-Up
6L80, 6L45, 6L90, 6L80-E HD, 6L80-EHD
Login for personalized shopping
11.080" Overall Diameter, 11.50" Bolt Pattern, Mount Plate, 10mm x 1.5 Thread, Flats/Step/Flange Hub, 1.702" Pilot Diameter, 1.01" Pilot Length, 36 Spline, Low Stall Speed; Codes: 24264543, 24279497, 24290214, 24280633, 24274485
8L90, 8L45
Login for personalized shopping
Remanufactured, 12" Body Diameter, Slotted Stepped Hub Type, 4 Mounts, Mount Plate Mount Type, 11.4" Bolt Circle, 1.375" Pilot Outside Diameter, 0.9" Pilot Length, No Ring Gear, BL3P BA, 9016 Stamped Code, Medium Stall, 32 Turbine Splines
6R80
Login for personalized shopping
Remanufactured, 11.1" Body Diameter, Stepped Slotted Hub Type, 3 Mounts, Raised Pad with Captive Lugs Mount Type, 11.5" Bolt Circle, 1.702" Pilot Outside Diameter, 0.64" Pilot Length, No Ring Gear, 2426 8442, 2427 9756 Stamped Codes, 36 Turbine Splines
6L80, 6L90
Login for personalized shopping
Remanufactured, 12.185" Body Diameter, Slotted Hub Type, 3 Mounts, Stepped Pads Mount Type, 11" Bolt Circle, 1.7" Pilot Outside Diameter, No Ring Gear, VJCX Sticker Codes, Medium/HIgh Stall, 30 Turbine Splines, Lock-Up
4L60-E
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Slotted Hub Type, 3 Mounts, Drilled Pads Without Threads Mount Type, 10.75" Bolt Circle, 1.703" Pilot Outside Diameter, No Ring Gear, 1400-1600 Stall, 30 Turbine Splines, No Lock-Up
THM400, THM350, THM350C, AT218, Powerglide, Super Turbine 300
Login for personalized shopping
Remanufactured, 12.2" Body Diameter, 2 Flats with Groove Hub Type, 4 Mounts, Pad Mount Type, 10" Bolt Circle, 1.815" Pilot Outside Diameter, 0.86" Pilot Length, No Ring Gear, 659AB Stamped Code, Low Stall, 29 Turbine Splines, Lock-Up
65RFE, 66RFE, 8HP75, Torqueflite, 850RE
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Slotted Hub Type, 3 Mounts, Pad Mount Type, 11" Bolt Circle, 1.703" Pilot Outside Diameter, No Ring Gear, TMBX, 24206642, 24213393, 24214393, 24222971, 24222974, 24227088, 24227944, 24227948 Stamped Codes, 1400-1600 Stall, 30 Turbine Splines
4L60-E, 4L80-E, 4L65-E, 4L70-E, 4L60-E-HD
Login for personalized shopping
Remanufactured, 11.35" Body Diameter, Slotted/Stepped Hub Type, 3 Mounts, Pad Mount Type, 11" Bolt Circle, 1.336" Pilot Outside Diameter, 1.18" Pilot Length, No Ring Gear, 193K6 Stamped Code, High Stall, 22 Turbine Splines, Lock-Up
NAG1, W5A580
Login for personalized shopping
Reman, 1200 RPM Stall Speed, Billet Multi Disc, Billet Cover, Billet Stator Caps, Welded and Furnace Brazed Fins, Rated For 500 Horsepower and 1, 000 ft. lbs. torque, Rated For up To 10K lbs towing, Stage 1, Diesel Performance
68RFE
Login for personalized shopping
Remanufactured, 12.75" Body Diameter, Milled Flats Hub Type, 4 Mounts, Stud Mount Type, 11.375" Bolt Circle, 1.374" Pilot Outside Diameter, No Ring Gear, 71A, 84A, 99A Stamped Codes, 1600-1800 Stall, 31 Turbine Splines, Lock-Up
4R70W, AOD-E, 4R75W, 4R75E, 4R70E
Login for personalized shopping
10.050" Overall Diameter, 9.750" Bolt Pattern, Mount Plate, 10mm x 1.5 Thread, Flats/Step/Flange Hub, .824" Pilot Diameter, 1.415" Pilot Length, 27 Spline, Low Stall Speed; Codes: 24279503, 24280302, 24293013, 24274130, 24285732, 24298484
8L45
Login for personalized shopping
