Torque Converters
Transend - Products List
Remanufactured, 12.5" Body Diameter, Slotted Stepped Hub Type, 3 Mounts, Stepped Pads Mount Type, 11" Bolt Circle, 1.701" Pilot Outside Diameter, No Ring Gear, JMBX, 24236469, 24239789, 24245964, 24243221 Sticker Codes, Low Stall, 36 Turbine Splines, Lock-Up
6L80, 6L90, 6L80-E HD, 6L80-EHD, 6L80-E
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Slotted Hub Type, 3 Mounts, Stepped Pads Mount Type, 11" Bolt Circle, 1.701" Pilot Outside Diameter, 1.1" Pilot Length, No Ring Gear, TMBX, 24222971, 24227948, 24227944, 24206642 Sticker Codes, Low Stall, 30 Turbine Splines, Carbon Woven Clutch Friction Type, Lock-Up
4L60-E, 4L65-E, 4L70-E, 4L60-E-HD
Login for personalized shopping
All New Components Converter, Updated Design Reduces Cover Flex and Eliminates Shudder, Pilot Dia. 43.22MM, Hub Dia. 46.564MM, Overall Dia. 315.5MM, Body Dia. 283.3MM, Mounting Plate Design Distributes Engine Torque Across 12 Contact Points on the Body of the Converter Compared to 3 Lugs Directly Under Apply Surface of the OE Design. Replaces; JMBX, 19435460, 24247371, 19419378, 24247372, 19366835; (USE 3 OF TRANSTAR PART # M464GE FOR CONVERTER BOLTS)
6L80
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Slotted Stepped Hub Type, 3 Mounts, Billet Cover RSD Pads Mount Type, 11" Bolt Circle, 1.701" Pilot Outside Diameter, No Ring Gear, JMBX, 24236469, 24239789, 24245964, 24243221 Sticker Codes, Low Stall, 36 Turbine Splines, Lock-Up, Billet Cover, Heavy Duty Bearing
6L80, 6L45, 6L90, 6L80-E HD, 6L80-EHD
Login for personalized shopping
Remanufactured, 12.732" Body Diameter, Milled 2 Flats Stepped Hub Type, 4 Mounts, Threaded Studs, Oval Pads Mount Type, 11.375" Bolt Circle, 1.375" Pilot Outside Diameter, No Ring Gear, High Stall, 31 Turbine Splines, Lock-Up
E4OD, 4R70W, AOD-E, 4R75W, 4R75E, 4R70E
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Stepped Slotted Flanged Hub Type, 3 Mounts, Stepped Pads Mount Type, 11" Bolt Circle, 1.702" Pilot Outside Diameter, No Ring Gear, JMBX, 24242396, 24242397, 24238202, 24245962, 24243219 Sticker Codes, Low Stall, 36 Turbine Splines, Lock-Up
1000, 6L80, 6L45, 6L90, 6L80-E HD, 6L80-EHD
Login for personalized shopping
Remanufactured, 10.75" Body Diameter, Flats/Flanged Hub Type, 4 Mounts, Pads Mount Type, 9" Bolt Circle, No Ring Gear, 447AB, 520AA, 520AB, 527AA, 527AB, 538AA, 538AB, 556AA, 556AB, 556AC, 557AA, 557AB, 557AC, 559AC Stamped Codes, Low Stall, 22 Turbine Splines, Electronically Modulated Converter Clutch Grooved Clutch Friction Type, Lock-Up
62TE, 62TEA
Login for personalized shopping
Remanufactured, 13.4" Body Diameter, Slotted/Flanged Hub Type, 6 Mounts, Drilled & Tapped Pads Mount Type, 12.25" Bolt Circle, 1.811" Pilot Outside Diameter, No Ring Gear, Low Stall, 23 Turbine Splines, Lock-Up, Billet Cover
46RE, 47RE, 48RE, 47RH
Login for personalized shopping
Remanufactured, 13.5" Body Diameter, Milled 2 Flats Hub Type, 6 Mounts, Stepped Pads Mount Type, 11.5" Bolt Circle, 1.703" Pilot Outside Diameter, No Ring Gear, 12491334, 17803871, 24210825, 24210830, 24210831, 24217235 Sticker Codes, High Stall, 35 Turbine Splines, Lock-Up
4L80-E, 4L80-E-HD/MN8, 4L85-E
Login for personalized shopping
Remanufactured, 11.25" Body Diameter, Milled 2 Flats Flanged Hub Type, 4 Mounts, Stepped Pads Mount Type, 9.75" Bolt Circle, 0.825" Pilot Outside Diameter, 0.835" Pilot Length, No Ring Gear, 7G7, 7G6, 9A Stamped Code, Low Stall, 27 Turbine Splines, Lock-Up
6T70, 6T75, 6T45, 6T80
Login for personalized shopping
Remanufactured, 10.473" Body Diameter, Milled 2 Flats Flanged Hub Type, 4 Mounts, Threaded Studs, Round Pads Mount Type, 8.858" Bolt Circle, 0.824" Pilot Outside Diameter, 0.84" Pilot Length, No Ring Gear, FW2MA Stamped Code, C, D, H Sticker Codes, 3516 Stamped Codes, Low Stall, 24 Turbine Splines, Lock-Up
6F35
Login for personalized shopping
Remanufactured, 12.75" Body Diameter, Milled Flats Hub Type, 6 Mounts, Stud Mount Type, 11.375" Bolt Circle, 1.375" Pilot Outside Diameter, No Ring Gear, AC, AD, AF, WW, XX, ZZ Stamped Codes, 1500-1700 Stall, 31 Turbine Splines, Lock-Up
4R100
Login for personalized shopping
Remanufactured, 13.425" Body Diameter, Flats with Groove Hub Type, 6 Mounts, Threaded Holes Mount Type, 12.25" Bolt Circle, 2.124" Pilot Outside Diameter, 1.074" Pilot Length, No Ring Gear, 671AD, 671AE, 671AF, 671AG, 671AH, P52119671AG Stamped Codes, 1350 Stall, 27 Turbine Splines, Lock-Up
68RFE
Login for personalized shopping
Remanufactured, 12" Body Diameter, Slotted Hub Type, 3 Mounts, Rectangular Pads Mount Type, 10.75" Bolt Circle, 1.702" Pilot Outside Diameter, No Ring Gear, DGGF, DGPF, DHDF, DHHG, DHPF, DHPG, DKNF, DKPF, DLPH Stamped Codes, 1400-1600 Stall, 30 Turbine Splines, Carbon Woven Clutch Friction Type
4L60-E
Login for personalized shopping
Remanufactured, 12.5" Body Diameter, Stepped Slotted Flanged Hub Type, 3 Mounts, Billet Cover RSD Pads Mount Type, 11" Bolt Circle, 1.702" Pilot Outside Diameter, No Ring Gear, JMBX, 24242396, 24242397, 24238202, 24245962, 24243220 Sticker Codes, Low Stall, 36 Turbine Splines, Lock-Up, Billet Cover, Heavy Duty Bearing
1000, 6L80, 6L45, 6L90, 6L80-E HD, 6L80-EHD
Login for personalized shopping
Lock-Up, 12.95" Outside Diameter, 11.13" Bolt Pattern, 4 Stud, 10mm x 1.0 Thread, 4 Milled Flats Hub, 375" Pilot Dia, Codes: HL3P-AD, HL3P-AE, HL39-AD, HL39-AE; Converter Nut Part # M474FB
10R80
Login for personalized shopping
