Pumps & Stators

Requires Assembly **Stator Shaft Bolts Requires Torque, Follow the Torque Procedure** One Top Bell Bolt Hole Type, Fits # 24236121, 24239892, 24239952 Casting, New Bushing and Seal, Incls Bell Housing Stator, Rotor Kit, 3 Mating Surfaces Machined, Bell To Stator Surface,Rotor Pocket, Bell To Case Surface, Sandblasted, Counter Boring Where Rotor Guide Rides, All Bolt Hole Threads To Mate Stator Are Chased With A Tap, Counter Sink To Bevel The Top Of Each Bolt Hole, Mating Surface, O/S Boost And P/R Valve, O/S TCC Feed Limit Valve

Snap Ring Holds In Front Seal Type, Snap Ring and Front Seal Included

Seal On Front Cover Plate Type, Includes Cover and Seal

Requires Assembly **Stator Shaft Bolts Requires Torque, Follow the Torque Procedure** Two Top Bell Bolt Hole Type, Fits # 24248033, 24248034 Casting, New Bushing and Seal, Incls Bell Housing Stator, Rotor Kit, 3 Mating Surfaces Machined, Bell To Stator Surface,Rotor Pocket, Bell To Case Surface, Sandblasted, Counter Boring Where Rotor Guide Rides, All Bolt Hole Threads To Mate Stator Are Chased With A Tap, Counter Sink To Bevel The Top Of Each Bolt Hole, Mating Surface, O/S Boost And P/R Valve, O/S TCC Feed Limit Valve

Stator, 36 Spline, 9-1/8" Long, Steel Ring Land, Non Rotational Ring Type **SERVICE TIP; Add Part # 104211A and T104531CK**

Cast # 5C3P, No Remote Filter

Pump Cover & Stator, 36 Spline, 9-1/8" Long, Steel Ring Land, Non Rotational Ring Type, Includes Rings and Seals; Failure to Follow PI1404 May Result In the Rejection of Warranty Claim; Must Be Cleaned with Kerosene or Mineral Spirits Before Install

.700" Wide Bushing

Front Seal On Front Front Cover Plate Type, Included Front Cover and Seal

Seal On Front Cover Plate Type, With Updated TCC Limit Valve

7.300" Shaft, No O-Ring, With Speed Sensor Hole

Steel Type; Molded Seal

Seal On Front Cover Plate Type, No Torque Converter Clutch Accumulator Valve In Pump Type

Steel Coast Drum Type; Pulse Width Modulated (PWM) Seal Ring Above Stator Bushing

1.250" ID Stator Bushing, With Groove For Stator Sealing Ring, Lock-Up

.590" Thick Milled Flat Gear Type, Bushing for Converter Hub, No Front Stator Busing Type
